Brief
- 94 kms lenght. 48 " diameter
- 6 Pumps x 26.003/day
- 2 Emerging Pumps
- Conduit Pipe API 5L X360
Work done
- Developed and updated the 3D model in Autocad Plant 3D
- Isometric drawings
- P & ID drawings
- Bill of materials (BOM)
- Piping class
- Data sheets
